Seamless, deep and drawn aluminum alloy body, ensures maximum sealing and, thanks to its light weight, perfect handling. Externally painted with polyester resin.
The valve is sprinkler type, with nichel plated body, equipped with a charge indication pressure gauge and sintered filter to protect the sensitive elements.
ABC multi-purpose dry extinguishing powder, certified according to EN 615."
The propellant gas is nitrogen. A small percentage of helium is added to allow electronic leak detection.
4 pieces cardboard box, robust and suitable for transport.
| FIRE RATINGS | A B C | |
| CHARGE | 2 kg ± 5% | |
| MATERIAL | Aluminum | |
| CYLINDER | Manufacturing process | Deep Drawing |
| External painting | ||
| Corrosion resistance | ||
| EXTINGUISHING AGENT | ABC POWDER A32 | |
| PROPELLANT | N2 + HE | |
| DISCHARGE | Discharge time | ~ 0 s |
| PRESSURE | Operating pressure at 60 °C | 11 bar |
| Operating pressure at 20 °C | 9 bar | |
| Operating pressure at -30 °C | 6 bar | |
| DIMENSIONS | Overall height | 379 mm |
| Bottle outer diameter | 108 mm | |
| WEIGHT | Empty / Charged | 0.59 kg / 2.59 kg |
| PACKING SPECIFICATIONS | Standard packing | 4 Pieces cardboard box |
| Carton size (B x L x H) | 240 x 245 x 405 mm | |
| Weight per carton | 11.43 kg | |
| Pallet | 60 Cartons | |
| Pallet size (B x L x H) | 800 x 1200 x 1764 mm | |
| Pallet volume | 1.68 m3 | |
| Weight per pallet (net/gross) | 686 kg / 706 kg |
| Description | Code |
|---|---|
|
O-RING 23,40 X 3.53 |
00.006B.5010.00K0 |
|
PRESSURE GAUGE |
00.245E.4951.10K0 |
|
SPRINKLER VALVE 68°C; M30X3 PILTZ |
00.321E.6960.10K0 |
|
SPRINKLER VALVE 79°C; M30X3 PILTZ |
00.321E.6960.20K0 |
|
SPRINKLER VALVE 93°C; M30X3 PILTZ |
00.321E.6960.30K0 |
|
TRANSPORT BRACKET |
00.800B.2961.00K0 |
|
O-RING 7.66 x 1.78 |
00.800F.4800.00K0 |
|
BULB 68°C |
P500.SP.0068.00K0 |
|
CAP WITH BULB 68°C |
P500.SP.0068.T0K0 |
|
BULB 79°C |
P500.SP.0079.00K0 |
|
CAP WITH BULB 79°C |
P500.SP.0079.T0K0 |
|
BULB 93°C |
P500.SP.0093.00K0 |
|
CAP WITH BULB 93°C |
P500.SP.0093.T0K0 |
