WS9-IJ Li

Stored pressure
Water
Water with complement
9 L
Temperature ranges
0° + 60°
On Request
BODY
STAINLESS STEEL

Stainless steel cylinder, wire feed welded. Externally painted with polyester resin.

VALVE
ACETALYC RESIN

Squeeze grip lever operated valve with acetal resin body, ensuring perfect protection against corrosion. The shock-proof pressure gauge is equipped with a non-return valve to allow pressure control and with a sintered filter to protect sensitive parts.

EXTINGUISHING AGENT

Water with specific additives (SORIK Li) to increase class A performance, suitable for extinguishing lithium batteries. All parts in contact with the extinguishant are compatible.

PROPELLANT

The propellant gas is nitrogen. A small percentage of helium is added to allow electronic leak detection.

HOSE/HORN

The EPDM reinforced rubber hose guarantees perfect flexibility and resistance within the temperature range. Complete with nozzle.

PACKAGING

Single piece cardboard box, robust and suitable for transport.

WS9-IJ Li
43
Configuration
Standard
On request
BRACKET
Button holed wall bracket
Button holed wall bracket PG-M E FG-M
TRASPORT BRACKET PS9-H
PACKAGING
BOX PS9 J/HJ
HOSE RINGS & PROTECTIVE BASE
PORTASUPPORTO VALV.J C/DADO S/VITE
FONDELLO PLASTICA C/PORTAM D190;VERDE

Technical data

FIRE RATINGS 43A
CHARGE 9 L 0 / -5%
MATERIAL STAINLESS STEEL
CYLINDER Manufacturing process Deep Drawing
External painting Polyester Resin
Corrosion resistance 480 H SECONDO ISO 9227
EXTINGUISHING AGENT WATER WITH ADDITIVES
PROPELLANT N2 + HE
DISCHARGE Discharge time ~ 66 s
PRESSURE Operating pressure at 60 °C 13 bar
Operating pressure at 20 °C 11 bar
Operating pressure at 0 °C 9 bar
DIMENSIONS Overall height 630 mm
Bottle outer diameter 190 mm
WEIGHT Empty / Charged 3.85 kg / 12.85 kg
PACKING SPECIFICATIONS Standard packing 1 Pieces cardboard box
Carton size (B x L x H) 650 x 200 x 200 mm
Weight per carton 13.3 kg
Pallet 48 Cartons
Pallet size (B x L x H) 800 x 1200 x 1460 mm
Pallet volume 1.38 m3
Weight per pallet (net/gross) 620 kg / 640 kg

Spare parts list

Description Code
BUTTON HOLED WALL BRACKET
00.005E.2900.00K0
WALL BRACKET
00.005E.2950.00K0
O-ring valve
00.033E.1100.01K0
TRANSPORT BRACKET
00.241F.2900.00K0
SCHRADER VALVE
00.600A.5100.00K0
SEAL
00.652A.5030.VEK0
WALL BRACKET
00.752B.2900.10K0
PRESSURE GAUGE
00.814E.4950.20K0
SUPPORT DE LANCE
00.850E.2955.20K0
Green button
00.850E.5100.40
SAFETY PIN
00.850E.5300.00K0
VLV ASSY W/O PRESS.GAUGE W/LEV
00.860E.8505.00K0
ASSEMBLED HOSE
00.860F.2400.05K0
DIP TUBE
00.890E.5900.00K0
Base Ø190
00.890F.7100.10
HOSE HOLDER Ø190
00.895F.2800.00K0
